EDIL-THERM® PIR-ALU

RIGID PIR INSULATION BOARD WITH ALUMINUM FACING ON BOTH SIDES

EDIL-THERM® PIR-ALU is a polyiso (PIR) insulation board faced with aluminum for flat and pitched roofs (warm roof) and floors. It is not an ETICS board: it is used where very high insulation in limited thickness is needed under the roof covering or the floor.

With λD 0.15 BTU·in/(h·ft²·°F) (0.022 W/(m·K)), thicknesses from 13/16 to 11 3/4 in (20 to 300 mm) and compressive strength ≥ 17 psi (≥ 120 kPa), it can be bonded, mechanically fixed or ballasted.

NOTE

PIR with aluminum facings; λD 0.15 BTU·in/(h·ft²·°F) (0.022 W/(m·K)).
Thicknesses 13/16 to 11 3/4 in (20-300 mm); compressive strength CS ≥ 17 psi (≥ 120 kPa).
Installation: bonded, mechanically fixed or ballasted.
